Audi specifications

Year: 2017 (Gen 1)

Engine
Type:                    2.0-litre straight-four engine with turbocharger and intercooler
Power (max):     246 kW (330hp) @ 6200 rpm
Torque (max):   410Nm @ 2500 rpm

Transmission
Type:                   Front-wheel drive
SEQ:                    Six-speed sequential racing gearbox
Differential:       Mechanical, preload adjustable
Clutch:                Multi-disc, sintered

Cockpit
Seat:                    Audi Sport customer racing Seat PS-3 (FIA GT3 safety seat)
Controls:            Height and reach-adjustable steering column with shift paddles on the steering wheel
Car Check:         Control Auto-diagnosis OBDII / DiagRA-LE

Chassis
Front axle:          MacPherson struts; height, track and camber of chassis can be adjusted; anti-roll bar can be adjusted in three stages
Rear axle:            Multi-link axle, height, track and camber of chassis can be adjusted; anti-roll bar can be adjusted in three stages
Dampers:           Adjustable
Steering:             Electric rack-and-pinion with modified software and hardware
Front brakes:     Discs (378mm x 34mm) with internal ventilation, aluminium six-piston calipers
Rear brakes:        Discs (272mm x 12mm) with internal ventilation, two-piston calipers
Wheels: 10 x 18-inch

Bodywork
Structure:             Strengthened production steel body with welded steel roll-cage
Bodywork:            Parts from steel panel, CFC and GFC
Length:                 4589mm
Width:                   1950mm
Height:                  1340mm
Fuel tank:             100 litres
Wheelbase:          2665mm
Weight (dry):       1180kg
Race weight:     1285kg including driver (or as per TCR regulations)

Performance
Acceleration: 0-100km/h approx. 4.5 seconds
Top Speed: Approx. 240km/h
